| Operating as a dedicated manufacturer delivering robust industrial solutions, we present our highly efficient horizontal rotary transfer machine. This equipment is specifically configured for complex valve bodies requiring extended processing. By utilizing our factory equipment, you gain access to multi-station combined processing systems designed for unmatched precision and reliable industrial-scale production. | |||||||||
|
| |||||||||
Unlike standard vertical counterparts, our horizontal waterwheel machine is specifically engineered for machining complex valve bodies and components requiring extended processing capabilities. The equipment features robust synchronous hydraulic vices to secure materials firmly during intensive operations. We configure power head distribution according to specific product definitions ensuring precise execution across every automated cycle. Our system easily integrates robot manipulators for optimized loading and unloading factory workflows.
Parameter | Typical Configuration |
Spindle count | 7-10 spindles (configurable) |
Work stations | 6-station indexing table (1 load/unload + 5 machining) |
Spindle speed | Boring: ~1335 rpm / Tapping: ~556 rpm |
Our multi-station rotary machine offers exceptional flexibility with a configurable setup of seven to ten spindles. We adjust the power head axles strictly according to your distinct product features. Operators benefit from precise spindle speeds reaching 1335 rpm for boring and 556 rpm for tapping. This versatility ensures high-performance drilling and threading across various dense industrial materials without compromising designated cycle times.
Sustained machining generates significant heat requiring reliable thermal management solutions. We equip our CNC valve machining equipment with versatile cooling mechanisms including direct water cooling, targeted spraying, and gas injection methods. These integrated systems protect your tooling investments while maintaining the structural integrity of processed components. Consistent temperature control directly contributes to tighter tolerances and superior surface finishes on all completed parts.
Where vertical machines excel at simpler, smaller components, the horizontal rotary transfer machine delivers industrial-scale capability-more stations, more spindles, more complexity, all in a single automated cycle. Building upon this solid foundation, our heavy-duty factory equipment effortlessly handles a large number of processing operations for surface valves and multi-station combined processing. We engineer the entire platform to maximize your facility output, ensuring that complex components meet the most demanding industrial production requirements without compromising precision.
Modern manufacturing facilities require adaptable equipment to maintain competitive production speeds. While manual loading is standard, our machinery seamlessly supports robotic manipulators to fully automate the feeding process. A sturdy six-station indexing table divides tasks intelligently between one load/unload station and five active machining zones. This continuous workflow drastically reduces idle time while boosting overall output for highly demanding industrial operations.
This horizontal configuration is the preferred solution for:
 Multi-port valve bodies requiring drilling from multiple angles |  Complex sanitary and industrial valves with intricate internal passages |  High-volume valve production where part complexity demands more than 12 stations |  Automotive and hydraulic valve components with tight tolerance requirements |
Our system perfectly accommodates complex multi-port bodies requiring precise drilling from multiple intricate angles simultaneously. We engineered the indexing table to securely position these challenging parts for sequential machining operations without requiring any manual realignment. This advanced configuration guarantees exact hole placement across every single port, thereby reducing your factory scrap rates significantly during mass production runs.
High-pressure environments demand exceptionally tight tolerance requirements for all integrated fluid control parts used daily. Our horizontal equipment reliably mills, bores, and taps these rugged industrial components to meet exact engineering specifications precisely. You achieve the consistent geometric accuracy that remains absolutely essential for preventing critical leaks in complex heavy-duty fluid management systems worldwide.
Certain industrial production lines face extreme component complexity demanding extended processing capabilities across numerous stages. We tailor our robust horizontal systems specifically to streamline these intensive manufacturing flows into highly manageable automated cycles. Our specialized machinery sustains continuous high-speed output for massive production orders while maintaining strict dimensional accuracy across every finished batch.
Selecting the right supplier partner ensures you receive equipment perfectly matched to your strict production goals. We leverage deep manufacturing expertise to supply robust machinery engineered for actual factory floor conditions. Our dedicated technical team evaluates your specific component drawings to customize power head distributions and gripper designs. You receive comprehensive support from initial consultation through final machine commissioning at your facility.
Our equipment effectively machines brass, steel, aluminum, and various heavy-duty alloys commonly used in complex fluid control manufacturing.
Yes, while standard operations utilize manual loading, we readily integrate robotic manipulators to fully automate your factory production cycle.
The standard configuration features a sturdy six-station indexing table comprising one dedicated load/unload zone and five active machining stations.
1. Application: A large number of processing operations for surface valves and multi-station combined processing, etc.
2. Power head distribution: According to the definition of products
3. Gripper: Synchronous hydraulic vice.
4. Loading/unloading method: Manual loading/unloading.Robot or manipulator can be a plus
5. Tool cooling system: Water cooling, spraying, gas injection andother cooling methods.
6. Make the number of power head axles according to productfeatures.
Watch our Vertical waterwheel special machine with gas tank valve in action.
